LED Grille Panel Light
Panel Light

LED Grille Panel Light

The LED Grille Panel Light is a high‑efficiency, anti‑glare lighting solution designed for modern commercial interiors. Featuring a sleek grille design that effectively reduces direct glare, it provides comfortable, uniform illumination with high lumen output.Available in various sizes and wattages, it delivers significant energy savings compared to traditional fluorescent grille lights.

Key Specifications

    {pboot:if(High Lumen Output: Up to 100–120 lm/W
    Energy Efficient: Saves up to 90% energy
    Long Lifespan: 50,000 hours
    Premium LED Chips & Driver: Flicker-free, stable performance
    High CRI (≥80/90): True color rendering
    Color Temps: 3000K / 4000K / 6000K
    Power:20W/meter
    Easy Install!='')}
  • check_circle High Lumen Output: Up to 100–120 lm/W
    Energy Efficient: Saves up to 90% energy
    Long Lifespan: 50,000 hours
    Premium LED Chips & Driver: Flicker-free, stable performance
    High CRI (≥80/90): True color rendering
    Color Temps: 3000K / 4000K / 6000K
    Power:20W/meter
    Easy Install
  • {else}
  • No specifications available
  • {/pboot:if}



 SPECIFICATIONS
ModelSC-PLG-30120-40W
Electrical
Parameter
Input Voltage100-277VAC
Working Frequency50/60Hz
Input Power40W ± 5%
PFPF>0.9
Optical
Parameter
LED SourceSMD2835 LED
LED Numbers384 SMD2835
CCT3000K/4000K/5000K/6000K
Lumen4800Lm± 5%
Lumen Efficiency>120Lm / W
CRIRa>90 / RA>97 (Optional)
Beam angle109°
Dimmable0-10V Dimming (Optional)
StructureMaterialAluminum + PC
Type of power supplyCE, ROHS, Isolated Driver
Product SizeL1195mm x W295mm x H50mm
Working TemperatureTemperature: -25℃~55℃; Humidity: ≤90%
PackagingMaterialCarton Box
Carton sizeL1240mm x W345mm x H335mm
Pcs/Carton4 Pcs
Net Weight17Kg
Gross Weight20Kg
Quantity / Container20’ GP: 800PCS / 40’ GP: 1680PCS / 40’ HQ: 1920PCS

Application:

Ideal for offices, schools, hospitals, retail stores, supermarkets, conference rooms, libraries, showrooms, and other commercial spaces where visual comfort and uniform lighting are essential.
