LED Flood Light Linear IC Driver
Flood Light

LED Flood Light Linear IC Driver

The Linear IC Driver LED Flood Light is a driverless (DOB/Linear IC), ultra-slim outdoor luminaire engineered for cost-effective, high-reliability area illumination. By integrating high-voltage Linear IC driving technology directly onto the LED circuit board, it eliminates bulky electrolytic capacitors, resulting in a compact, low-profile body, enhanced lifespan, and exceptional thermal stability.

Key Specifications

    {pboot:if(High Lumen Output: Up to 100–120 lm/W
    Energy Efficient: Saves up to 90% energy
    Long Lifespan: 50,000 hours
    Premium LED Chips & Driver: Flicker-free, stable performance
    High CRI (≥80/90): True color rendering
    Color Temps: 3000K / 4000K / 6000K
    Power:30W/50W/100W/150W/200W/300W
    Easy Install!='')}
  • check_circle High Lumen Output: Up to 100–120 lm/W
    Energy Efficient: Saves up to 90% energy
    Long Lifespan: 50,000 hours
    Premium LED Chips & Driver: Flicker-free, stable performance
    High CRI (≥80/90): True color rendering
    Color Temps: 3000K / 4000K / 6000K
    Power:30W/50W/100W/150W/200W/300W
    Easy Install
    • {else}
  • No specifications available
    • {/pboot:if}
Inquire Now
Features
Product Name:  LED Flood Light SS-FLC
Input Voltage Range:   AC100-265V
Life Span:              50,000+ Hours
Warranty:  3Years
Driver Brand:   Inbuild Linear IC Driver
Dimmable: Not dimmable
Beam Angle: 120°
Materials:  Aluminum ADC#12
Color Tolerance:SDCM<5, Optional<3
Power Factor: >0.90
Lumen Output: 100lm~120lm/W
CRI (RA): >70
LED Chips brand:   LUMILEDS/EPISTAR
LED Type: SMD
Color Temperature:3000K / 4000K / 5000K / 5700K
THD: <35%
Operating Temperature: -40 °C to +60 °C
IK rating: IK10
IP rating:  IP66
Protection class IEC: Safety class I
InstallationSurface mounted
House Color: Sanded grey/black
Frequency:50/60 Hz
Surge Protection: 4KV
Relative Humidity:Up to 90% RH
Cable Length:30cm 3x0.75mm²


Application：

Ideal for building exterior walls, commercial billboards, architectural signage, parking lot perimeters, garden security lighting, residential yards, warehouse loading docks, and construction boundaries.
